Introduction#

Dealing with drag and drop can be hard, specially if you don't have much experience with any libraries focused on that. There are a lot of very good libraries out there that makes it easier to work with drag and drop, like react-dnd and react-draggable, but our focus today is on building a kanban (basically a board with draggable columns and cards) with react-beautiful-dnd.

react-beautiful-dnd#

react-beatiful-dnd is a library focused on making it easy to have list with draggables and reordable elements. Feel free to check it on the links below:

• react-beatiful-dnd examples
• react-beatiful-dnd repo
• react-beatiful-dnd free course

Initiating project#

I will be using create-react-app and typescript for this tutorial.

Create initial project structure using CRA then open it in your favorite code editor, Vistual Studio Code in my case.

npx create-react-app react-beautiful-dnd-kanban --template typescript

code react-beautiful-dnd-kanban

After some cleaning up in the project initial structure (check the changes here), we need to add the react-beautiful-dnd library and its types.

yarn add react-beautiful-dnd

yarn add -D @types/react-beautiful-dnd

And that's it! Now we can create the kanban components.

Kanban Components#

We can divide the kanban in simple three components, the board, the column and the card. The board is just a droppable zone, because you can move and drop columns in it. The column is a droppable zone (because you can drop cards in it) and also and draggable (because you can drag it and change the columns order). The card is a draggable, you can drag around columns.

We will start by coding the board (we can say it's the same as the Kanban, because everything is inside it):

import { DragDropContext, Droppable } from 'react-beautiful-dnd';

export const Kanban = () => {
  return (
    <DragDropContext onDragEnd={() => console.log('Drag has ended')}>
      <Droppable droppableId="columns" direction="horizontal" type="COLUMN">
        {(provided) => (
          <div ref={provided.innerRef} {...provided.droppableProps}>
            <h3>Hello World</h3>
          </div>
        )}
      </Droppable>
    </DragDropContext>
  );
};

Column:

import { Draggable, Droppable } from 'react-beautiful-dnd';

type ColumnProps = {
  id: string,
  index: number
};

export const Column = ({ id, index }: ColumnProps) => (
  <Draggable draggableId={id} index={index}>
    {(draggableProvided, snapshot) => (
      <div
        ref={draggableProvided.innerRef}
        {...draggableProvided.draggableProps}
      >
        <Droppable droppableId={id} type="COLUMN">
          {(droppableProvided, snapshot) => (
            <div
              ref={droppableProvided.innerRef}
              {...droppableProvided.droppableProps}
            >
              <h1>Column</h1>
            </div>
          )}
        </Droppable>
      </div>
    )}
  </Draggable>
);
